HYDRAULIC OIL PUMP DOUBLE BODY 14+2.5 cc LEFT – AFTERMARKET – 02030330

€491,14 (€ 402,57 + IVA)

Modified type
to be completed with the following secondary pump fittings, not included:
n.01 reduction 3/8″ Male / M14x1,5 Female
n.01 reduction 1/2″ Male /M18x1,5 Female
Total length 190 mm. excluding shaft
flange centering diameter 80 mm.
Standard Group 2 Tapered Shaft
14cc displacement main pump with 4-hole flanges
M6 intake, 40 mm centre distance.
M6 thread, centre distance 35 mm.
2.5 cc secondary pump with threaded connections
suction 1/2″ GAS = 21 mm.
mandate 3/8″ GAS = 16.5 mm.
Counterclockwise rotation shaft side view

Related Products:

1 in stock

To check compatibility with your vehicle, scroll down

Additional information

Weight 4,27 kg
Net weight

4.27 Kg
Brand

Item number

02030330
Codifiche precedenti
3725
SKU: CP02030330

Do you have the product code?


Read what they say about us on Trustpilot

Description



This item is a compatible product for the following vehicles:

  • Goldoni – Star 3070 V – Star 3000 V from serial number D503343
    with serial number D528784
    corresponding to John Deere 2070V – Tractor     – Engine: VM D703LT     double pump 2P14 / 1,7
    from serial number E533370
  • Goldoni – 70 – Quasar from serial number A496144
    up to serial number B537151 – Tractor     – Engine: VM D703LT     serial number B
  • Goldoni – 85 – Quasar from serial number A496144
    up to serial number B537151 – Tractor     – Engine: VM D704LTE     serial number B
  • Goldoni – 85 – Quasar from serial number C535037
    up to serial number D586197 – Tractor     – Engine: VM D704TE2
  • Goldoni – 85 – Star Quadrifoglio from serial number C524073
    up to serial number C588258 – Tractor     – Engine: VM D704TE2     model 2P14 / 1,7
  • Goldoni – 100 – Star Quadrifoglio from serial number C524073
    up to serial number C588258 – Tractor     – Engine: VM D754TE2 41A     model 2P14 / 1,7
  • Goldoni – Star 3070 V – Star 3000 V from serial number E533370
    to serial number E541942
    corresponding to John Deere Milenio 70V – Tractor     – Engine: VM D703TE1 Vers. 17A     double pump 2P14 / 1,7
    from serial number E533370
  • Goldoni – Star 3070 V – Star 3000 V from serial number E541943
    corresponding to John Deere Milenio 70V – Tractor     – Engine: VM D703TE2 vers. 17A     double pump 2P14 / 1,7
    from serial number E533370
  • Goldoni – 85 – Star Quadrifoglio from serial number C524073
    up to serial number C588258 – Tractor     – Engine: VM D704LTE     model 2P14 / 1,7
